Peplink MAX BR1 Pro 5G

Tags Mobile Global Marine Global Mobile GMTS Connect 5G Cellular Fits Antenna Max Rugged Peplink

SKU MAX-BR1-PRO-5GN-T-PRM

● Request a quote. No payment is taken. Login to view trade pricing.

Configuration

PrimeCare licence

Hardware only (year in the box) 1-year licence 2-year licence 4-year licence

Details about this licence

On by default: 2 extra years of PrimeCare extended warranty, software and support on top of the year in the box (3 years cover in total). Untick for hardware only.

PrimeCare is Peplink vendor care for the licence term, not a separate GMTS 3-year warranty SKU. It covers:

Extended hardware warranty, firmware/software updates, and technical support
InControl 2 cloud management
SpeedFusion Connect (SFC, formerly SpeedFusion Cloud): Peplink-hosted SpeedFusion endpoints so you can bond, smooth, or hot-failover WANs without a second Peplink at the far end

Active PrimeCare includes an SFC usage allowance. The quota depends on the router tier. After that allowance, SFC keeps running at a reduced speed unless you add extra SFC capacity. Hardware-only quotes keep the year in the box and do not add a care or SFC line.

Optional extras

Peplink 4-pin to USB-C power cable

Virtual WAN licence

None

Virtual WAN licence (1 extra VLAN WAN)

Virtual WAN licence (2 extra VLAN WAN)

Virtual WAN licence (3 extra VLAN WAN)

Off by default. Ticked extras add as a separate quote line.

Request a quote Talk to GMTS

Rugged single-5G MAX for vehicles, plant, and exposed trays - Wi-Fi 6, 2.5G WAN, SpeedFusion. Request a quote.

The BR1 Pro 5G is the rugged single-modem MAX: one 5G radio, Wi-Fi 6, a 2.5G Ethernet WAN, and SpeedFusion so Starlink and cellular can cover each other without anyone touching the box. It is the core of a performance rugged kit with Antenna Max, and the step below BR2 Pro when you only need one cellular path.

Description

Peplink MAX BR1 Pro 5G (MAX-BR1-PRO-5GN-T-PRM).
Ignition sensing and 10-30 V DC for vehicle and plant trays.
Fits Antenna Max (non-PoE routers use Splitter Max on the Ethernet run).
Recommended users 1-150 (Peplink).

Wi-Fi

Wi-Fi 6, 2×2 MU-MIMO, simultaneous dual-band (2.4 GHz / 5 GHz).
AP and/or Wi-Fi WAN.
2× RP-SMA Wi-Fi antenna connectors.
Built-in AP controller (30 APs standard; 50 with licence add-on).

Modem

1× embedded 5G modem with redundant SIM slots.
Nano-SIM (4FF), Peplink eSIM, and bring-your-own eSIM (2 profiles, firmware 8.4+).
RemoteSIM / FusionSIM on hardware version 2 or above.
4× SMA cellular plus 1× SMA GPS.

Speeds

Router throughput 1 Gbps (Peplink).
SpeedFusion: 400 Mbps unencrypted / 200 Mbps 256-bit AES.
Cellular max theoretical: 5G 4.1 Gbps down / 900 Mbps up; LTE Cat-20 2 Gbps / 211 Mbps. Peak radio rates are not a site guarantee.
1× 2.5G Ethernet WAN and 2× gigabit LAN (WAN can be used as LAN).

Power

DC 10-30 V; AC adapter 100-240 V to 12 V.
8 W nominal, 19 W max (Peplink).
Operating temperature −40°C to 65°C.

Where it fits

Vehicles, plant, and exposed marine trays that need one 5G path plus a wired WAN (Starlink, fibre, or shore).
Step up to BR2 Pro when two independent 5G modems matter; Transit Duo Pro when the install is a vehicle with dual LTE; B One 5G when the site is indoor and you want two wired WANs in a quieter box.

Pair it with

Antenna Max or Mobility 42G for the cellular / Wi-Fi / GPS elements.
Splitter Max when the router has no PoE in and the only run is Ethernet.
Starlink Mini or Standard as a WAN; Virtual WAN licences if you need extra VLAN WANs.

Request a quote.

Use cases

Rugged single-5G Peplink for vehicles, plant, and exposed marine trays - SpeedFusion + PrimeCare.
Core of the performance rugged kit (Antenna Max + Splitter Max).
Bond Starlink Standard/Mini as a WAN; use Transit/BR2 when you need dual modems.
